EARTHQUAKER DEVICES Silos™

Multi-Generational Time Reflection Device

Unlike anything before it, the Silos™ merges together a digital, analog, and tape delay into one compact and powerful pedal. In addition to the tri-voice delay, it features tap tempo, user-assignable expression control, and the ability to save and recall six presets, making it endlessly customizable and easy to operate. It’s like having three classic pedals all rolled into one! Now you can save room on your pedalboard while never having to decide which single delay to use again.

3 Modes Of Impeccable Sounding Delay

Each of the three modes offers up to one second of delay time. From noon and back is 500 milliseconds to zero, which has its own character. From 500 milliseconds to one second of delay time, it’s an entirely different beast. Dial them in for shorter delay times where they really excel and add loads of atmosphere and vibes. Push them further for rhythmic delays that are perfect for strumming and adding extra ambiance for your riffs. Each of the three delay modes is uniquely different and offers its own unique character when selected.

Global Features

Pairs Perfectly With Distortion

Silos was meticulously designed to respond well to gain and overdrive saturation.

Presets

Silos has six available preset slots for you to save and recall your favorite settings. The settings for each of the three controls, the mode switch and the expression jack assignment can be saved and recalled in any of the slots.

Easily Switch Between Delay Modes

Silos has two operating modes which are extremely easy to switch between on the fly! In Live mode, the pedal will operate exactly where the controls are set and any changes will have no effect on the presets unless saved. In Preset mode, stored presets (including expression pedal mapping) are selected using the Preset switch, and the physical settings of the controls will be ignored.

User-Assignable Expression Control

Use any TRS expression pedal to take control over the Time, Repeats or Mix.

Controls

Mode Toggle: Toggles between Digital Delay, Analog Delay, and Tape Delay

Time: This sets the delay time from 0–1 second.

Repeats: This controls the regeneration of the delay signal. This mode does not self-oscillate in Digital Mode but begins to self-oscillate at 3 o’clock in Analog and Tape Modes.

Mix: Adjusts the level of the delay signal.

Preset: Six available preset slots for you to save and recall your favorite settings. The settings for each of the three controls, the Mode switch and the expression jack assignment can be saved and recalled in any of the slots.
